Product Overview

Product Details

DAYLIFF SUNFRIDGE Solar Refrigerators/Freezers are highly efficient DC energy saving refrigerators specifically designed for off-grid solar PV powered applications including residential homes, camps and medical centres. They can be used either as refrigerators or freezers due to the fully programmable temperature control and feature an air forced fin-coil condenser that assures top cooling performance.

The Dayliff SUNFRIDGE offers the following features:

  • Opening top chest design, 55/128 single lid and 233 double lid
  • Selective temperature setting that provides either fridge or freezer application
  • Multifunction LED display of operating parameters including battery power and temperature
  • 12 or 24VDC power input with automatic selection
  • Inbuilt protection against reverse polarity, battery deep discharge
  • Bottom drain plug for easy cleaning, lockable lid with interior light
  • Internal basket to separate fridge contents
  • 110mm insulation wall and CFC free
  • 100% Copper Tube, Cooling System Enhanced
  • Extremely strong lid, hinge and freezer body
  • Low maintenance and easy to clean

Featuring the latest cooling technology in combination with optimized electronic regulation and compressor speed control, Dayliff SUNFRIDGE provide optimal use of energy which results in lower input power requirements and the highest standards of quality, reliability and long service life.

TECHNICAL SPECIFICATIONS

 MODEL SUNFRIDGE 55   SUNFRIDGE 128  SUNFRIDGE 233
 Storage Volume (Litres)  55  130  240
 Operating Temperature Range    -20°C to +10°C
 Nominal Solar Power Requirement  80W  125W  150W
 Energy Consumption per 24hrs  0.302kWhr  0.46Whr  0.6Whr
 Battery Size Requirement 100Ah    150Ah
 Charge Controller Requirement 10A    15A
 Power Supply 12/24VDC
 DC Input Voltage 10VDC.17VDC/17VDC.31.5VDC
 DC Reconnection Voltage (LVR)    11.5/23.9V
DC Deep Discharge Protection (LVD) 10.2/22.5V
Operating Ambient Temperature 10ºC to 43°C
Internal Dimensions (LxWxH)  430x230x315 513x530x585  993x516x594
External Dimensions (LxWxH) 650x450x535 733x750x805 1213x736x814
Weight (kg)  28 47   66
