Product Details

The Dayliff DDV submersible pump is a unique design of submersible pumps specially applicable for small scale water supply from drums, tanks, domestic wells or rivers.

Features

• Positive displacement type using a vibrating diaphragm which is efficient and also has the capacity to handle light silt loads.
• Compact construction and robust design
• Installed by suspension in a well, drum or tank
• Aluminum construction throughout with diaphragm made of rubber
• Intergral motor designed for maximum 1 hr operating periods
• Enclosure Class: IP68
• Insulation Class: B
• Voltage: 1x240V



OPERATING CONDITIONS
Pumped liquids: Thin, clean, sweet liquids containing light silt loads.
Liquid temperature: 0⁰C to +40⁰C
Max. Operating Pressure: 8 bar
Max Immersion Depth: 3m
